NTA-2233 Bearing | Loyal
NTA-2233 PDF download| NTA-2233 interchange KOYO NTA-2233 | |
| NTA-2233 cross reference KOYO NTA-2233 | |
| NTA-2233 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NTA-2233 |
| H | 53.19 |
| d | 34,93 mm |
| D | 52,375 mm |
| T | 1,9837 mm |
| Cu | 10.5 |
| Dc | 52.375 |
| d1 | 52.37 |
| Dw | 1.9837 |
| Eb | 37,08 mm |
| Ca | 21.35 |
| Ea | 49,53 mm |
| C0a | 103.20 |
| Dc1 | 34.93 |
| Noun | Roller Assembly |
| UNSPSC | 31171500 |
| Bore 1 | 1.375 Inch | 34.925 Millimeter |
| Banded | No |
| Height | 0.078 Inch | 1.981 Millimeter |
| Bore 2 | 1.375 Inch | 34.925 Millimeter |
| h(max) | 0.81 |
| h(min) | 0.76 |
| S(max) | 34.93 |
| Weight | 0,01 Kg |
| S(min) | 34.85 |
| Category | Thrust Roller Bearings |
| Inventory | 7.0 |
| Size (mm) | 34.93x52.375x1.9837 |
| Width (mm) | 1,9837 |
| Bearing No. | NTA-2233 |
| Weight / LBS | 0.023 |
| Product Group | B04144 |
| Self Aligning | No |
| Cage Material | Steel |
| Inch - Metric | Inch |
| Bearing number | NTA-2233 |
| Keyword String | Thrust Needle |
| Other Features | Single Row | Two Piece Cage |
| Thrust Bearing | Yes |
| Rolling Element | Needle Roller Bearing |
| Precision Class | ABEC 1 | ISO P0 |
| Outside Diameter | 2.063 Inch | 52.4 Millimeter |
| Long Description | 1-3/8" Bore 1; 1-3/8" Bore 2; 2-1/16" Outside Diameter; 5/64" Height; Needle Roller Bearing; Single Direction; Not Self Aligning; Not Banded; Steel Cage; ABEC 1 | ISO P0; Roller As |
| (Refer.)Mass(kg) | 0.010 |
| Manufacturer URL | http://www.koyousa.com |
| Weight / Kilogram | 0.01 |
| Manufacturer Name | KOYO |
| Washer designation | TRA-2233 |
| Bore Diameter (mm) | 34,93 |
| Outer Diameter (mm) | 52,375 |
| Minimum Buy Quantity | N/A |
| Component Description | Roller Assembly Only |
| Limiting speeds(min-1) | 8000 |
| Harmonized Tariff Code | 8482.99.25.40 |
| (Refer.)Washer mass(kg) | 0.007 |
| Manufacturer Item Number | NTA-2233 |
| Single or Double Direction | Single Direction |
| Basic static load rating (C0) | 103,2 kN |
| Basic dynamic load rating (C) | 21,35 kN |
| Overall Height with Aligning Washer | 0 Inch | 0 Millimeter |
