NTA-3648 Bearing | Loyal
NTA-3648 PDF download| NTA-3648 interchange KOYO NTA-3648 | |
| NTA-3648 cross reference KOYO NTA-3648 | |
| NTA-3648 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NTA-3648 |
| H | 76.99 |
| d | 57,15 mm |
| D | 76,2 mm |
| T | 1,984 mm |
| Cu | 14.6 |
| Dc | 76.2 |
| d1 | 76.20 |
| Dw | 1.984 |
| Eb | 59,44 mm |
| Ca | 24.78 |
| Ea | 71,628 mm |
| C0a | 142.34 |
| Dc1 | 57.15 |
| Noun | Roller Assembly |
| UNSPSC | 31171500 |
| Height | 0.078 Inch | 1.981 Millimeter |
| Banded | No |
| Bore 1 | 2.25 Inch | 57.15 Millimeter |
| Bore 2 | 2.25 Inch | 57.15 Millimeter |
| h(max) | 0.81 |
| h(min) | 0.76 |
| S(max) | 57.15 |
| Weight | 0,017 Kg |
| S(min) | 57.07 |
| Category | Thrust Roller Bearings |
| Inventory | 107.0 |
| Size (mm) | 57.15x76.2x1.984 |
| Width (mm) | 1,984 |
| Bearing No. | NTA-3648 |
| Weight / LBS | 0.038 |
| Product Group | B04144 |
| Self Aligning | No |
| Cage Material | Steel |
| Inch - Metric | Inch |
| Bearing number | NTA-3648 |
| Keyword String | Thrust Needle |
| Other Features | Single Row | Two Piece Cage |
| Thrust Bearing | Yes |
| Rolling Element | Needle Roller Bearing |
| Precision Class | ABEC 1 | ISO P0 |
| Long Description | 2-1/4" Bore 1; 2-1/4" Bore 2; 3" Outside Diameter; 5/64" Height; Needle Roller Bearing; Single Direction; Not Self Aligning; Not Banded; Steel Cage; ABEC 1 | ISO P0; Roller Assembl |
| Outside Diameter | 3 Inch | 76.2 Millimeter |
| (Refer.)Mass(kg) | 0.017 |
| Manufacturer URL | http://www.koyousa.com |
| Weight / Kilogram | 0.016 |
| Manufacturer Name | KOYO |
| Bore Diameter (mm) | 57,15 |
| Washer designation | TRA-3648 |
| Outer Diameter (mm) | 76,2 |
| Minimum Buy Quantity | N/A |
| Component Description | Roller Assembly Only |
| Limiting speeds(min-1) | 5600 |
| Harmonized Tariff Code | 8482.99.25.40 |
| (Refer.)Washer mass(kg) | 0.012 |
| Manufacturer Item Number | NTA-3648 |
| Single or Double Direction | Single Direction |
| Basic static load rating (C0) | 142,34 kN |
| Basic dynamic load rating (C) | 24,78 kN |
| Overall Height with Aligning Washer | 0 Inch | 0 Millimeter |
