32026XU Bearing | Loyal
32026XU PDF download| 32026XU interchange NTN 32026XU | |
| 32026XU cross reference NTN 32026XU | |
| 32026XU Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | 32026XU |
| a | 43,5 mm |
| B | 45 mm |
| C | 34 mm |
| e | 0.43 |
| d | 130 mm |
| D | 200 mm |
| T | 45 mm |
| Sa | 8 mm |
| Sb | 11 mm |
| Y2 | 1.38 |
| Y0 | 0.76 |
| Mass | 4.96 kg |
| Weight | 4,96 Kg |
| r min. | 2,5 mm |
| rs min | 2 mm |
| db min | 144 mm |
| Da min | 178 mm |
| Da max | 190 mm |
| da max | 142 mm |
| Db min | 192 mm |
| ra max | 2 mm |
| r1s min | 2 mm |
| Db min. | 192 mm |
| r1a max | 2 mm |
| ra max. | 2 mm |
| Da max. | 190 mm |
| da min. | 142 mm |
| r1 min. | 2 mm |
| db max. | 144 mm |
| ra1 max. | 2 mm |
| Category | Bearings |
| Size (mm) | 130x200x45 |
| Inventory | 0.0 |
| Nlim (oil) | 2,200 rpm |
| Width (mm) | 45 |
| Product Group | B04334 |
| Nlim (grease) | 1,700 rpm |
| Bearing number | 32026XU |
| Static load, C0 | 545 kN |
| Dynamic load, C | 320 kN |
| Weight / Kilogram | 0 |
| ISO 355 reference | T4EC130 |
| Manufacturer Name | NTN |
| Bore Diameter (mm) | 130 |
| Outer Diameter (mm) | 200 |
| Minimum Buy Quantity | N/A |
| Calculation factor (e) | 0,43 |
| (Oil) Lubrication Speed | 2 200 r/min |
| Calculation factor (Y0) | 0,76 |
| (Grease) Lubrication Speed | 1 700 r/min |
| Rating life coefficient, A2 | 1 |
| Basic static load rating (C0) | 545 kN |
| Basic dynamic load rating (C) | 320 kN |
| Max operating temperature, Tmax | 120 °C |
| Min operating temperature, Tmin | -40 °C |
