NUP314R Bearing | Loyal
NUP314R PDF download| NUP314R interchange KOYO NUP314R | |
| NUP314R cross reference KOYO NUP314R | |
| NUP314R Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NUP314R |
| C | 35 mm |
| d | 70 mm |
| D | 150 mm |
| B | 35 mm |
| B2 | - |
| Cu | 33.4 |
| Ew | - |
| d1 | - |
| B1 | - |
| Cr | 256 |
| Fw | 89 mm |
| C0r | 222 |
| r min. | 2.1 mm |
| Weight | 2.81 Kg |
| r(min) | 2.1 |
| da(min) | 81 |
| db(min) | 81 |
| db(max) | 87 |
| dc(min) | - |
| r1(min) | 2.1 |
| dd(min) | - |
| Da(max) | 139 |
| Db(max) | - |
| Db(min) | - |
| r1 min. | 2.1 mm |
| ra(max) | 2 |
| rb(max) | 2 |
| Oil lub. | 5300 |
| Size (mm) | 70x150x35 |
| Width (mm) | 35 |
| Grease lub. | 4000 |
| Bearing No. | NUP314R |
| Bearing number | NUP314R |
| (Refer.)Mass(kg) | 2.95 |
| Bore Diameter (mm) | 70 |
| Outer Diameter (mm) | 150 |
| (Grease) Lubrication Speed | 4000 r/min |
| Basic static load rating (C0) | 222 kN |
| Basic dynamic load rating (C) | 205 kN |
