NUP314 Bearing | Loyal
NUP314 PDF download| NUP314 interchange NTN NUP314 | |
| NUP314 cross reference NTN NUP314 | |
| NUP314 Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | NUP314 |
| J | 98 mm |
| D | 150 mm |
| F | 90 mm |
| C | 35 mm |
| E | 130 mm |
| B | 35 mm |
| d | 70 mm |
| Fw | 90 mm |
| d1 | 98 mm |
| rs min | 2.1 mm |
| r min. | 2,1 mm |
| da min | 81 mm |
| Weight | 2,71 Kg |
| ra max | 2 mm |
| Da max | 139 mm |
| dc min | 100 mm |
| r1s min | 2.1 mm |
| r1 min. | 2,1 mm |
| Category | Bearings |
| Inventory | 0.0 |
| Size (mm) | 70x150x35 |
| Nlim (oil) | 5,500 rpm |
| Width (mm) | 35 |
| Product Group | B04144 |
| Nlim (grease) | 4,700 rpm |
| Bearing number | NUP314 |
| Static load, C0 | 168 kN |
| Dynamic load, C | 158 kN |
| Weight / Kilogram | 2.843 |
| Manufacturer Name | NTN |
| Bore Diameter (mm) | 70 |
| Outer Diameter (mm) | 150 |
| Minimum Buy Quantity | N/A |
| Fatigue limit load, Cu | 19.9 kN |
| Mass (without HJ ring) | 2.84 kg |
| Radial clearance class | CN |
| (Grease) Lubrication Speed | 4 700 r/min |
| Basic static load rating (C0) | 168 kN |
| Basic dynamic load rating (C) | 158 kN |
| Max operating temperature, Tmax | 120 °C |
| Min operating temperature, Tmin | -40 °C |
| Characteristic cage frequency, FTF | 0.41 Hz |
| Characteristic inner ring frequency, BPFI | 7.68 Hz |
| Characteristic outer ring frequency, BPF0 | 5.32 Hz |
| Characteristic rolling element frequency, BSF | 5.32 Hz |
