GEZ 400 ESX-2LS Bearing | Loyal
GEZ 400 ESX-2LS PDF download| GEZ 400 ESX-2LS interchange SKF GEZ 400 ESX-2LS | |
| GEZ 400 ESX-2LS cross reference SKF GEZ 400 ESX-2LS | |
| GEZ 400 ESX-2LS Equivalent bearing interchange guide： | |
| Price： | enquiry |
| Model Number： | GEZ 400 ESX-2LS |
| D | 158.75 mm |
| d | 101.6 mm |
| B | 88.9 mm |
| C | 76.2 mm |
| b | 10.5 mm |
| M | 8 mm |
| α | 6 ° |
| α | 6 ° |
| Size (mm) | 158.75x101.6x88.9 |
| Lubricant | Maintenance free – greased for life |
| Width (mm) | 88,9 |
| b1 | 10 mm |
| b1 | 10 mm |
| dk | 146.05 mm |
| dk | 146.05 mm |
| Bearing number | GEZ 400 ESX-2LS |
| Sealing solution | Triple-lip seals |
| da max. | 115.5 mm |
| da min. | 108 mm |
| r2 min. | 1 mm |
| r1 min. | 0.6 mm |
| Da min. | 139.5 mm |
| Da max. | 152.5 mm |
| ra max. | 0.6 mm |
| rb max. | 1 mm |
| Mass plain bearing | 7 kg |
| Bore Diameter (mm) | 158,75 |
| Outer Diameter (mm) | 101,6 |
| da - min. | 108 mm |
| r2 - min. | 1 mm |
| r1 - min. | 0.6 mm |
| rb - max. | 1 mm |
| ra - max. | 0.6 mm |
| Da - max. | 152.5 mm |
| Da - min. | 139.5 mm |
| da - max. | 115.5 mm |
| Constant - KM | 330 |
| Basic dynamic load rating C | 1340 kN |
| Basic dynamic load rating - C | 1340 kN |
| Specific dynamic load factor K | 150 N/mm² |
| Material constant KM | 330 |
| Specific factor dinamic load - K | 150 N/mm2 |
| Basic static load rating C0 | 2650 kN |
| Basic static load rating - C0 | 2650 kN |
| Specific static load factor K0 | 300 N/mm² |
| Specific factor static load - K0 | 300 N/mm2 |
| Design (sliding contact surface combination) | Steel/steel |
