Tapered Roller Bearings
- Tapered Roller Bearings - TS (Tapered Single)
- Standard type
- All
1～20/742
- Tapered Roller Bearings
- Tapered Roller Bearings - TS (Tapered Single)
- Standard type
- All
| Bearing No. | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Series | r - Cup Backface "To Clear" Radius2 | Design Units | Db - Cup Backface Backing Diameter | da - Cone Frontface Backing Diameter | D - Cup Outer Diameter | d - Bore | Cup Part Number | Cone Part Number | |
| 71.... | 32319 | 3 mm0.12 in | 4 mm0.16 in | 261.5 | METRIC | 180.1... | 124 mm4.88 in | 185.9 mm7.32 in | |
| 63 ... | 33220 | 2.5 mm0.1 in | 3 mm0.12 in | 256.3 | METRIC | 160 m... | 122 mm4.8 in | 172 mm6.77 in | |
| 56 ... | 33122 | 2 mm0.08 in | 2.5 mm0.1 in | 285 | METRIC | 162 m... | 130 mm5.12 in | 173.5 mm6.83 in | |
| 91 ... | 32234 | 4 mm0.16 in | 5 mm0.2 in | 858.1 | METRIC | 279 m... | 210 mm8.27 in | 293.5 mm11.56 in | |
| 104... | 32240 | 4 mm0.16 in | 5 mm0.197 in | 1227.1 | METRIC | 326 m... | 240 mm9.45 in | 340 mm13.39 in | |
| 97 ... | 32238 | 4 mm0.16 in | 5 mm0.2 in | 1114.6 | METRIC | 305 m... | 230 mm9.05 in | 323 mm12.72 in | |
| 91 ... | 32236 | 4 mm0.16 in | 5 mm0.2 in | 988.6 | METRIC | 288 m... | 220 mm8.66 in | 303 mm11.93 in | |
| 149... | 32260 | 5 mm0.197 in | 6 mm0.236 in | 3303.4 | METRIC | 483.1... | 359 mm14.13 in | 511 mm20.12 in | |
| 127... | 32248 | 4 mm0.16 in | 5 mm0.2 in | 2021.3 | METRIC | 394 m... | 293 mm11.54 in | 415 mm16.34 in | |
| 54 ... | 32314 | 2.5 mm0.1 in | 3 mm0.12 in | 141.9 | METRIC | 133 m... | 94 mm3.7 in | 140 mm5.51 in | |
| 137... | 32252 | 5 mm0.2 in | 6 mm0.24 in | 2419.2 | METRIC | 432 m... | 315 mm12.4 in | 454.5 mm17.89 in | |
| 36 ... | 33016 | 1.5 mm0.0... | 1.5 mm0.06 in | 139.4 | METRIC | 115 m... | 90 mm3.54 in | 120 mm4.72 in | |
| 45 ... | 32938 | 2 mm0.08 in | 2.5 mm0.1 in | 695.8 | METRIC | 242.1... | 205 mm8.07 in | 251 mm9.88 in | |
| 63.... | 32952 | 2.5 mm0.1 in | 3 mm0.12 in | 1503.1 | METRIC | 337 m... | 280 mm11.02 in | 347.5 mm13.68 in | |
| 59 ... | 33030 | 2.5 mm0.1 in | 3 mm0.12 in | 541.5 | METRIC | 207 m... | 169 mm6.65 in | 218 mm8.58 in | |
| 76 ... | 32960 | 3 mm0.12 in | 4 mm0.16 in | 2228.2 | METRIC | 393 m... | 324 mm12.76 in | 405.5 mm15.96 in | |
| 114... | 32244 | 4 mm0.16 in | 5 mm0.2 in | 1607.6 | METRIC | 362 m... | 268 mm10.55 in | 379.5 mm14.94 in | |
| 51 ... | 32948 | 2.5 mm0.1 in | 3 mm0.12 in | 1020.3 | METRIC | 300 m... | 258 mm10.16 in | 311.5 mm12.26 in | |
| 98.... | 32326 | 5 mm0.2 in | 5 mm0.2 in | 557.1 | METRIC | 251 m... | 171 mm6.73 in | 261 mm10.28 in | |
| 72 ... | 30244 | 4 mm0.16 in | 5 mm0.2 in | 1012.1 | METRIC | 364 m... | 252 mm9.92 in | 371 mm14.61 in | |
